Safety for underground mining

Pilz – Safe automation, automation technology - Pilz INT

To completely exclude a potential hazard, it is essential to comply with the prescribed minimum values for water flow, water pressure and air pressure when the nozzles are used. The automation system PSS 4000 now takes the place of the previous system in monitoring the nozzles and the machine – with an optimised function range. As a result, if any nozzles are blocked or lost, for example, this can be detected safely. Depending on the machine, PSS 4000 also offers Sandvik the opportunity to adapt the parameter settings again, or if necessary, the end user can do this himself – within the scope of parameters enabled by Sandvik. Another benefit: each machine can be produced in series, as the solution can be used on various machine types. So the new nozzle monitoring system with PSS 4000 hits the mark as regards operability and operational safety – for total safety underground.

The safety requirements for mining machines are high; a long and complex process ensues before the machine is ready for use. To meet all the necessary safety specifications, the technology “behind it” must be programmed, tested and then installed on the machine. As Pilz was a long-standing and experienced development partner, Sandvik also had them on board for the Sandvik MB670-1 Bolter Miner, which is used in longwall coal mining. The ambitious goal of the Austrian mining machine manufacturer is to guarantee reliable explosion protection, among other things. The solution: today, the automation system PSS 4000 provides safe nozzle monitoring SMS III on the Bolter Miner – and the safe small controller PNOZmulti 2 performs safety functions such as emergency stop.

The Austrian company Sandvik Mining and Construction G.m.b.H. develops and produces heading and mining machines for cutting mineral and ore deposits and excavating road tunnels worldwide. The competence centre for the development, engineering and production of continuous mining machines and mobile conveyor systems is located at its site in Zeltweg. The site has a history spanning more than 170 years and – like its products and services – belongs organisationally to the Sandvik Mining and Rock Solutions division.
